Product Details:
|
| Model NO.: | QHCSD-128 | Slot Type: | CTS |
|---|---|---|---|
| Customized: | Customized | Condition: | New |
| Warranty: | 2 Year | After-sales Service: | Lifelong |
| Total Length: | 31.1 | Total Width: | 5.5m |
| Total Depth: | 1.48m | Total Weight: | 90t |
| Main Engine Brand/Power: | Cummins /456kw | Auxiliary Engine Power: | 145kw |
| Pump Size: | 250ND | Head: | 53m |
| Dredging Depth: | 8m | Discharge Distance: | 1000m |
| Discharge Pipe Diameter: | 350mm | Cutter Head Power: | 64kw |
| Anchor Boom Length: | 9m | Cutter Head Diameter: | 1200mm |
| Total Fuel Consumption: | 67kw | Transport Package: | In Bulk |
| Specification: | Capacity 300m3/h | Trademark: | Set Sail |
| Origin: | China | HS Code: | 895100000 |
| Supply Ability: | 10000 Set/Year | Package Size: | 3100.00cm * 550.00cm * 150.00cm |
| Package Gross Weight: | 85000.000kg | Lead Time: | 40 Days (1 - 1 Sets) To Be Negotiated ( > 1 Sets) |
| Type: | Cutter Suction Dredger | Power Type: | Diesel |
| Cyclone Type: | Cast Iron Cyclone | Samples: | US$ 5000/Set 1 Set(Min.Order) | |
| Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
| : | Initial Payment Full Payment | Currency: | US$ |
| Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
| Dredging depth | 8m |
| Capacity | 300m3 |
| Discharge distance | 1000m |
| Draft | 0.8m |
| Total weight | 90t |
| Total length | 31.1m |
| Total width | 5.5m |
| Total hight | 1.48m |
| Main pump size | 250ND |
| Water flow | 1500m3 |
| Head diameter | 1450mm |
| Speed | 11/22/33 |
| Discharge distance pipe diameter | 350mm |
| Main engine power/brand | 456kw |
| Auxiliary engine power /brand | 122kw |
| Pump Gearbox brand | Fada |
| Speed ratio | 2:1 |
| Hydraulic gearbox brand | Fada |
| Cutter head diameter | 1450mm |
| Cutter head power | 64kw |
| Spud diameter /wall thickness | 377mm*16mm |
| Spud Length | 11.5m |
| Spud weight | 3.42t |
| swing winch wire rope diameter | 20m |
| Lifting winch wire rope diameter | 20mm |
| trolley moveing distance | 6m |
| Oil cylinder diameter | 160mm |
| Hydraulic system brand | Rexroth/Huade |
| Anchor weight | 250kg |
| Diesel engine | Normally cummins on dredger Cater .Weichai Yuchai and other can available |
| Cutter head | Generally drive power hydraulic . Electric power cutter head can offer |
| Generator set | Cummins brand generator set Weichai brand others can available |
| Hydraulic system | Hydraulic control system from Germany Rexroth |
| PLC system | PLC adopts advanced system from Germany Siemens |
| 1 | Cutter suction dredger is widely used in the river lake .sea .inland waterway and reservoir so on for dredging project |
| 2. | Cutter suction dredger is helpful for the port construction and match the wash sand equipment for project |
| 3. | Cutter suction dredger can match the mining machinery to get the gold and diamond etc. |
| 4. | Cutter suction dredger is suitable for all kinds of working situation , especially river with the high sand content and large project |
| 5. | Design of cutter suction dredger can reach the more dredger depth . we can make the design according to the dredging depth working site. |
7.Question for reply:
|
| 2. How many maximum dredging depth ? |
| 3.How many kilo meter is your discharge distance ? |
