Product Details:
|
| Model NO.: | QH-2 | Slot Type: | CTD |
|---|---|---|---|
| Customized: | Customized | Condition: | New |
| Warranty: | 1 Year | After-sales Service: | Lifelong |
| Engine Brand: | Cumins . Yuchai .Weichai | Pump Brand: | Shijiazhuang |
| Hydraulic Brand: | Rexroth Parker Hede | Gearbox Brand: | Fada |
| Dredging Depth: | 2m-30m | Max.Discharge Distance: | 6000m |
| Max.Water Flow: | 30000m3 | Max. Total Length: | 70m |
| Application: | River Sand Lake Mud Port Inland Waterway Reservoir | Max.Width: | 15m |
| Max. Hight: | 10m | Draft: | 1-3m |
| Generator Sets: | Stanford | Diesel Engine Power: | 224-3300kw |
| Hydraulic Winch Brand: | Hangzhou Fada | Transport Package: | Container |
| Specification: | Capacity 160m3-30000m3 | Trademark: | Set Sail |
| Origin: | China | HS Code: | 895100000 |
| Supply Ability: | 2000set /Year | Package Size: | 3900.00cm * 880.00cm * 270.00cm |
| Package Gross Weight: | 230000.000kg | Lead Time: | 45 Days (1 - 1 Sets) To Be Negotiated ( > 1 Sets) |
| Type: | Cutter Suction Dredger | Power Type: | Diesel |
| Cyclone Type: | Hydrocyclone | Samples: | US$ 5000/Set 1 Set(Min.Order) | |
| Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
| : | Initial Payment Full Payment | Currency: | US$ |
| Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
| 1 | Cutter Head | 9 | Signal Light Support | 17 | Ventilator |
| 2 | Pulley for Ladder | 10 | Control Cabin Base | 18 | Spud |
| 3 | Pulley for Swing | 11 | Diesel Engine | 19 | Discharge Pipe |
| 4 | Anchor | 12 | 3 phase Electric Motor | 20 | Spud Holder |
| 5 | Pulley for A-shape Portal Frame | 13 | Diesel Engine | 21 | Rail |
| 6 | A-shape Portal Frame | 14 | Gearbox | 22 | Suction Pipe |
| 7 | Swing Winch | 15 | Slurry Pump | ||
| 8 | Control Cabin | 16 | Main Pontoon Cover |
| Hydraulic cutter head rate to add the solid concentration. mixture through the suction pipe into the discharge pipe by the pressure pump to arrived the destination .( power is from hydraulic electric or both together) |
Best parts will be used for the dredgers, like world famous Cumins engines, Shijiazhuang pumps, Hangzhou gearboxes, Simens PLC control system.
Hydraulic system is one of the most important parts of cutter suction dredgers. The cutter head, ladder winch, swing winches, spud or spud carriage are driven by hydraulic motors for higher efficiency and durability. Reputed brands are used for the other hydraulic parts like hydraulic pipes, hydraulic pumps, hydraulic valves.
| Item | Water flow(m3) | Capacity (m3) | Mainly engine | Auxiliary engine | Discharge distance(m) | Dredging depth(m) | Cutter head power |
| 8 inch | 800m3 | 160m3 | 230kw | 100kw | 1000m | 8m | 50kw |
| 10 inch | 1500m3 | 300m3 | 456kw | 122kw | 1100m | 10m | 64kw |
| 12 inch | 2000m3 | 400m3 | 557kw | 200kw | 1200m | 12m | 108kw |
| 14 inch | 2500m3 | 500m3 | 582kw | 224kw | 1300m | 13m | 150kw |
| 16 inch | 3000m3 | 600m3 | 895kw | 298 kw | 1400m | 14m | 170kw |
| 18 inch | 3500m3 | 700m3 | 1137kw | 260kw | 1500m | 15m | 180kw |
| 20 inch | 5000m3 | 1000m3 | 1335kw | 405kw | 1500m | 15m | 260kw |
| 22 inch | 5500m3 | 1100m3 | 1491kw | 582kw | 1600m | 16m | 300kw |
| 24 inch | 6000m3 | 1200m3 | 1620kw | 700kw | 1600m | 18m | 450kw |
| 26 inch | 9000m3 | 1800m3 | 1950kw | 700kw | 2000m | 20m | 450kw |
| 1 | 1.More than 20 years factory . |
| 2 | 2.Exported over 50 countries . |
| 3 | 3.Over 500 projects worldwide . |
| 4 | 4.Famous brand equipment on our cutter suction dredger . |
| 5 | 5.Can offer the all customized cutter suction dredger size . |
| 6 | 6.All professional team for servicing customers. |
| 7 | 7.Timely safe and high efficiency delivery time. |
| 8 | 8.Flexible payment methods . |
| 9 | 9.safely transportation methods . |
1. factory can also customize all kinds of size dredger . |
2..Chain bucket sand and gold mining dredger : Set sail factory can produce sand chain bucket dredger . gold and diamond chain bucket dredger and land mining machinery so on |
3. Wheel bucket dredger .In addition Set sail factory can offer jet suction dredger trailing suction dredger multi-function service working boat sand transportation boat . sand washing production line etc |
