Product Details:
|
| Model NO.: | QHCSD-506 | Slot Type: | CTD |
|---|---|---|---|
| Customized: | Customized | Condition: | New |
| Warranty: | 2year | After-sales Service: | Lifelong |
| Total Length: | 16 Meter | Main Engine Brand And Power: | Cummins 582 Kw |
| Auxiliary Engine Power: | Cummins 224 Kw | Generator Power: | Cummins 30 Kw |
| Maximum Dredging Depth: | 13 Meter | Inner Pipe Diameter: | 400mm |
| Water Flow: | 2500 Cubic Meter | Capacity: | 500 Cubic Meter |
| Discharge Distance: | 1500 Meter | Cutter Head Diameter: | 1450mm |
| Cutter Head Power: | 108kw | Bottom Plate Thickness: | 10mm |
| Side Plate Thickness: | 8mm | Deck Plate Thickness: | 8mm |
| Front Plate Thickness: | 14mm | Transport Package: | Canvas |
| Specification: | 16 Inch Cutter Suction Dredger | Trademark: | Set Sail |
| Origin: | Qingzhou City Shandong Province China | HS Code: | 8905100000 |
| Supply Ability: | 10000 Set/Year | Package Size: | 3100.00cm * 750.00cm * 200.00cm |
| Package Gross Weight: | 90000.000kg | Type: | Cutter Suction Dredger |
| Power Type: | Diesel | Cyclone Type: | Hydrocyclone |
| Samples: | US$ 2000/Set 1 Set(Min.Order) | | Customization: | Available | Customized Request |
| Shipping Cost : | About Shipping Cost And Estimated Delivery Time. | : | Initial Payment Full Payment |
| Currency: | US$ | Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
| 1 | Cutter suction dredger is suitable for inland waterways. lakes. rives of dredging. |
| 2 | Standard design. allowing early delivery and low price. |
| 3 | Cutter suction dredger has advantages of high output. low cost and convenent rapare. |
| 4 | Completely assembled and fully tested before delivery. |
| 5 | Cutter suction dredger adopt hydeaulic system. this system is very steady. it isn't easy to appear failure. |
| 6 | Simple rapid assembly and dismantling. |
| 7 | Ready for operation on arrival at site. |
| 8 | Dredging pump adopt diesel engine to transmission.the power is stonger and steady. |
| 9 | Spare parts available from stock. |
| 10 | Transportable by road. rail or sea. |
| 11 | Reliable hydraulic system. |
| 12 | Efficient fuel consumption. |
| Dredger Loa | 32.0m |
| Hull Size(L*B*H) | 19.0×7.5×2.0m |
| Main pontoon(L*B*H) | 13.8×3.5×2.0m |
| Side Pontoon(L*B*H) | 19.0×2.0×2.0m |
| Structure | Box-structure |
| Main Engine Brand&Power | Cummins 582kw/Jichai 540Kw |
| Auxiliary enging power | Cummins 224kw |
| Harbour Generator | Cummins 30kw/Jichai 30kw |
| Total Power | Cummins 836kw/Jichai 790kw |
| Dredging Pump | WarmTechnology |
| Discharge Pipr Inner Dia. | 400mm |
| Head | 45m |
| Max.Dredging Depth | 13m |
| Water Flow | 2500m³/h |
| Solid Sand Capacity | 500m³/h |
| Cutter head diameter | 1450mm |
| Cutter head power | 108kw |
| 1 | offer the solution and design before the sale. |
| 2 | Inquiry and consulting support. |
| 3 | Sample testing support. |
| 4 | View our Factory. |
| 5 | Training how to instal the machine, training how to use the machine. |
| 6 | Engineers available to service machinery overseas. |
| 1 | More than 25 years experience |
| 2 | More than 120 certificated engineers and technicians |
| 3 | Cooperated with famous ship design & research institute and Ocean University |
| 4 | Exported to more than 80 countries in all over the world |
| 1 | The capacity of the output per hour? |
| 2 | The max.dredging Depth ? |
| 3 | The max. discharge distance ? |
