Product Details:
|
| Model NO.: | DM-27 | Slot Type: | CTS |
|---|---|---|---|
| Customized: | Customized | Condition: | New |
| Warranty: | 2 Year | After-sales Service: | Lifelong |
| Power: | Diesel Engine Or Electrical | Application: | River .Lake .Sea. Reservoir |
| Processing Material: | Sand . Mud .Silt .Gravel | Diesel Engine Brand: | Cummins .Weichai .Yuchai |
| Diesel Engine Power: | 200kw-3000kw | Sand Pump Brand: | Shijiazhuang Industrial Factory |
| Water Flow: | 300-20000m3/H | Capacity: | 120-4000 M3/H |
| Hydraulic Brand: | Rexroth | Maximum Dredging Depth: | 8-30 Meter |
| Maximum Discharge Distance: | 800-5000 Meter | Optional Fitted: | Carriage . Depth Sounder . Water Flow Meter |
| PLC Brand: | Siemens | Draft: | 0.8-2meter |
| Total Length: | 18-50 Meter | Transport Package: | Naked Or Canvas |
| Specification: | Capacity 100-3000 M3/h | Trademark: | Set Sail |
| Origin: | China | HS Code: | 8905100000 |
| Supply Ability: | 5000set/Year | Package Size: | 3800.00cm * 750.00cm * 200.00cm |
| Package Gross Weight: | 180000.000kg | Type: | Cutter Suction Dredger |
| Power Type: | Diesel | Cyclone Type: | Hydrocyclone |
| Samples: | US$ 5000/Set 1 Set(Min.Order) | | Customization: | Available | Customized Request |
| Shipping Cost : | About Shipping Cost And Estimated Delivery Time. | : | Initial Payment Full Payment |
| Currency: | US$ | Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
Best parts will be used for the dredgers, like world famous Cummins engines, Shijiazhuang pumps, Hangzhou gearboxes, Simens PLC control system.
Hydraulic system is one of the most important parts of cutter suction dredgers. The cutter head, ladder winch, swing winches, spud or spud carriage are driven by hydraulic motors for higher efficiency and durability. Reputed brands are used for the other hydraulic parts like hydraulic pipes, hydraulic pumps, hydraulic valves. all configuration equipment are customized according to the request .
| Item /size | 8inch | 10 inch | 12inch | 18inch | 20inch | 24inch | 26inch |
| Capacity (m3) | 160 | 300 | 400 | 700 | 1000 | 1400 | 1800 |
| Dredging depth(m) | 8 | 8 | 12 | 15 | 15 | 18 | 18 |
| Discharge distance (m) | 1000 | 1000 | 1000 | 1500 | 1500 | 1500 | 1500 |
| Total weight (t) | 85t | 90t | 120t | 180t | 230t | 360t | 380t |
| Pump size | 250 | 350 | 400 | 450 | 500 | 600 | 650 |
| Water flow (m3) | 800 | 1500 | 2000 | 3500 | 5000 | 7000 | 9000 |
| Discharge pipe dia.(mm) | 250 | 350 | 400 | 450 | 500 | 600 | 650 |
| Diesel engine brand | Cummins | Cummins | Cummins | Cummins | Cummins | Cummins | Cummins |
| Main engine power(kw) | 230 | 456 | 557 | 1137 | 1335 | 1620 | 1950 |
| Auxiliary engine power(kw) | 100 | 122 | 200 | 260 | 405 | 700 | 700 |
| Cutter head power (kw) | 50 | 64 | 78/108 | 180 | 260 | 450 | 450 |
| Cutter head diameter(mm) | 1000 | 1200 | 1450 | 1800 | 2000 | 2400 | 2400 |
| Hydraulic gerbox brand | Fada | Fada | Fada | Fada | Fada | Fada | Fada |
| Hydraulic system brand | Rexroth | Rexroth | Rexroth | Rexroth | Rexroth | Rexroth | Rexroth |
| Anchor boom length(m) | 6 | 9 | 12 | 15 | 15 | 18 | 18 |
| trolley stroke(m) | 2.5-3.5 | 2.5-4 | 2.5-4 | 4-6 | 4-6 | 6-8 | 6-8 |
| Qingzhou Qihang Dredging Machinery Co., Ltd. is a professional Chinese manufacturer of mud dredgers.cutter suction boats.sand dredgers. sand pumpers. iron dressers and gold washers. With its solid credit foundation. accurate market positioning and strong technical power, our company has established and consolidated its speaking right in the mud dredger market. The cutter- suction mud dredgers of our company are sold to various parts of the world.With cutter-suction mud and sand dredgers as our major products. we have been developing our international market with all our strength. We have successfully exported our products to Brunei. Nigeria. Kazakhstan. Pakistan. Chad. Indonesia. the Philippines. Mongolia. Bengal, Korea, Liberia and other countries and regions. Based on our brilliant sales performance, we carry out a stricter requirement for our product quality and ensure that each of our machines is a highquality one. Our technicians exert a strict control over each step of products, including production, commissioning, inspection and delivery, so that each machine which is delivered to customers is a high-quality one. |
