32 Inch Cutter Suction Mud Dredger with 547L Total Fuel Consumption and Diesel Engine

32 Inch Cutter Suction Mud Dredger with 547L Total Fuel Consumption and Diesel Engine
32 Inch Cutter Suction Mud Dredger with 547L Total Fuel Consumption and Diesel Engine 32 Inch Cutter Suction Mud Dredger with 547L Total Fuel Consumption and Diesel Engine 32 Inch Cutter Suction Mud Dredger with 547L Total Fuel Consumption and Diesel Engine 32 Inch Cutter Suction Mud Dredger with 547L Total Fuel Consumption and Diesel Engine 32 Inch Cutter Suction Mud Dredger with 547L Total Fuel Consumption and Diesel Engine 32 Inch Cutter Suction Mud Dredger with 547L Total Fuel Consumption and Diesel Engine

Large Image :  32 Inch Cutter Suction Mud Dredger with 547L Total Fuel Consumption and Diesel Engine

Product Details:
Place of Origin: China
Certification: ISO 9000, ISO 14001，ISO 20000, ISO 14064, LEED, ISO 10012, ISO 17025
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Container
Delivery Time: Peak Season Lead Time: 1-3 months, Off Season Lead Time: one month
Payment Terms: LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram, Cash
Supply Ability: 2500set /Year
Contact Now

32 Inch Cutter Suction Mud Dredger with 547L Total Fuel Consumption and Diesel Engine

Description
Model NO.: QHCSD-293 Slot Type: CTS
Customized: Customized Condition: New
Warranty: 1 Year After-sales Service: Lifelong
Hull Size: 35*10.2*2.7m Output Pipe Diameter: 800mm
Maximum Dredging Depth: 18m Water Flow: 9000m3
Capacity: 1350m3-1800m3 Maximum Discharge Distance: 1500m
Cutter Head Diameter: 2400mm Cutter Power: 450kw
Total Weight: 380ton Main Engine Power: 2427kw
Auxiliary Engine Power: 736kw Diesel Engine Brand: Cumins
Total Fuel Consumption: 547L Hydraulic Control System: Rexroth /Ward
Electric System: PLC And ABB Transport Package: Canvas
Specification: 32inch Water Flow 9000m3 Trademark: Set Sail
Origin: China HS Code: 8905100000
Supply Ability: 1000 Sets Per Year Package Size: 4600.00cm * 930.00cm * 270.00cm
Package Gross Weight: 447000.000kg Type: Cutter Suction Dredger
Power Type: Diesel Cyclone Type: Hydrocyclone
Samples: US$ 3000/Set 1 Set(Min.Order) | Customization: Available | Customized Request
Shipping Cost : About Shipping Cost And Estimated Delivery Time.  : Initial Payment Full Payment
Currency: US$ Return&refunds: You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Hydraulic Pump diesel engine 32 Inch Cutter Suction Mud Dredger
1. Company profile:
The Cutter Suction Dredger of steel construction, the non self-propelled, dismountable type, is able to berth and dredge at any waters both in the coastal area and inland rivers, with similar conditions to that in navigation area "A" or below the "A"-line specified in code for inland river steel engineering ship manufacture of P. R. China.

The dredger can be used to excavate and transport cohesive sediment below the class III specified in code for dredging engineering construction technique issued by Ministry of Water Resources(MWR) of P. R. China.

The hull consists of three pontoons, one main pontoon (engine room), two side pontoons. All parts are dimensioned to allow the  dredger to be transported by road, rail or water. The dredger is equipped with a rapid connection-disconnection system for the pontoons, achieved using bolts at deck level, hull front and rear , and hooks at the bottom. Further salient features of the dredger are the dredger is powered by a Marine engine. the main engine is to drive the dredge pump and hydraulic pump. Hydraulic pump will in turn power other all equipments such as cutter, swing and ladder winches, and the spud rams etc.
The hull is of all welded, steel construction to give the dredger the necessary strength required for dredging operations. The side pontoons are connected to the main pontoon by means of bolts.
The hull steel plate used is CCSB (shipbuilding steel plate ) .
Hydraulic Pump Diesel Engine 32 Inch Cutter Suction Mud Dredger
 2. Cutter suction dredger introduce :

 Cutter Suction Dredgers are of the highest possible quality. ensuring a long lifetime with a minimum of maintenance. The maxmum capacity of 32 inch dredger can reach to from 1800-2700 m3 water flow can go up to 9000 m³/h, and digging depth to 1-25 meters, discharge distance to 200-3000 meters.

Hydraulic Pump Diesel Engine 32 Inch Cutter Suction Mud Dredger
Hydraulic Pump Diesel Engine 32 Inch Cutter Suction Mud Dredger
Hydraulic Pump Diesel Engine 32 Inch Cutter Suction Mud Dredger
Hydraulic Pump Diesel Engine 32 Inch Cutter Suction Mud Dredger

Hydraulic Pump Diesel Engine 32 Inch Cutter Suction Mud Dredger
Hydraulic Pump Diesel Engine 32 Inch Cutter Suction Mud Dredger

Hydraulic Pump Diesel Engine 32 Inch Cutter Suction Mud Dredger
Hydraulic Pump Diesel Engine 32 Inch Cutter Suction Mud Dredger



3. 32 inch cutter suction dredger parameter:
Total length 46m
Hull size  35*10.2*2.7m
Discharge pipe diameter 800mm
Water flow 9000m3/h
solid capacity  1350m3-1800m3
Discharge distance  1500m
Cutter head diameter 2400mm
Cutter head power 450kw
Draught 1.6m
Displacement  477ton
Total weight  380ton
Main engine power  Cumins 2427kw
Auxiliary engine power Cumins 736kw
Total fuel consumption  547 litre
Hydraulic control system  Rexroth
Electric control system  Siemens PLC

4. Product advantage :
1 Relable and high efficiency-improtant device is international brand
2 After sales service -engineer in the working site for installation and training ,24/7 technical support .
3 Provide free spare part for a year. then cost to offer service and spare part
4 Can dismantled and easy transportation
Hydraulic Pump Diesel Engine 32 Inch Cutter Suction Mud Dredger
Hydraulic Pump Diesel Engine 32 Inch Cutter Suction Mud Dredger
Hydraulic Pump Diesel Engine 32 Inch Cutter Suction Mud Dredger

Hydraulic Pump Diesel Engine 32 Inch Cutter Suction Mud Dredger
Hydraulic Pump Diesel Engine 32 Inch Cutter Suction Mud Dredger


Best parts will be used for the dredgers, like world famous Cumins engines, Shijiazhuang pumps, Hangzhou gearboxes, Simens PLC control system.

 Hydraulic system is one of the most important parts of cutter suction dredgers. The cutter head, ladder winch, swing winches, spud or spud carriage are driven by hydraulic motors for higher efficiency and durability. Reputed brands are used for the other hydraulic parts like hydraulic pipes, hydraulic pumps, hydraulic valves.

5.our service :

  1. Free dredger consultation and free product drawings
  2. Customize dredgers based on the client's actual dredging needs
  3. On-site visits and factory visit services provided by Set Sail
  4. Arrange 2-3 Set Sail senior engineer and technicians to enter the working site within 36 hours
  5. Free professional assembly, training and operating to make sure dredger operates smoothly
  6. 1-year warranty and Lifetime technical assistance
  7. Sign after-sales service agreement with Set Sail  clients
  8. Offer spare parts at a discounted price
  9. On-site parts available
  10. Set Sail company require responsible Sales team, design team, manufacture team available 24/7 to best serve clients
  11. Set Sail company signs a long-time after-sale service agreement with customers.we make an excellent filing of customers for long term following-up service.
6. why choose Set Sail cutter suction dredger :
  1. A wide range of use applications
  2. High efficiency, large output, far pump distance, low fuel consumption
  3. Full hydraulic control with Rexroth, Vickers
  4. Siemens PLC operation with the operation convenience
  5. Engine choice from Weicchai, Cumins and more.
  6. The modular design enables fast assembly with Set Sail seniors engineers
  7. Dredger components available in factories to allow short delivery times
  8. Control the working process of dredging and pumping, delivering dredged materials. lower cost;
  9. Follow manufacture guideline: CCS-ZC standard
  10. CE certificates acquired to prove high quality
  11. Western Dredge brand parts, easy to find globally
  12. Can choose reliable Chinese brand parts to lower costs
  13. Gain access to our sales team, design team, manufacture team 24/7
  14. Lifetime Technical Assistance
  15. Optional equipment is available such as Spud carriage, anchor boom.
7.FAQ:
Q1: Is Set Sail  a reliable company?
Qingzhou  Set Sail Dredging Machinery Equipment Co., Ltd. is located in Qingzhou City, Shandong Province, is a high-tech enterprise focusing on the investment, consultation, designing, manufacturing, assembly and operation management of environmental protection projects and machinery with more than 20 years' experience. Our factory covers 6000 m2 and has more than 100 employees.

Q2: What about the delivery?
We can offer our equipment by containers or bulk ship, just depend on your actual requests.
Set Sail  always has various dredgers, aquatic weed harvesters etc. in stock. Spare parts are available too. Thus the delivery time can be shortened.

Q3: What's the payment method?
We can accept T/T, L/C, WESTERN UNION and so on.

Q4: What's the warranty?
We provide 1 year warranty and free repair if quality problems emerge within warranty peride.

Q5: Why choose Set Sail company?
We are factory, so we can design and manufacture the suitable dredger, water cleaning boat, mining machinery according to clients' requirements, and our equipment have good quality and competitive price.
8. Certification:
Hydraulic Pump Diesel Engine 32 Inch Cutter Suction Mud Dredger
9. other information :Hydraulic Pump Diesel Engine 32 Inch Cutter Suction Mud DredgerHydraulic Pump Diesel Engine 32 Inch Cutter Suction Mud DredgerHydraulic Pump Diesel Engine 32 Inch Cutter Suction Mud Dredger
