Product Details:
|
| Model NO.: | CSD-4 | Slot Type: | CTS |
|---|---|---|---|
| Customized: | Customized | Condition: | New |
| Warranty: | 2 Year | After-sales Service: | Lifelong |
| Main Electric Power: | 1120kw | Auxiliary Electric Power: | 355kw |
| Dredging Depth: | 18 M | Discharge Distance: | 1500m |
| Concentration: | 30%-35% | Capacty: | 1050m3 |
| Cutter Head Diameter: | 1800mm | Cutter Power: | 180kw |
| Pump Size: | 450ndq | Discharge Pipe Diameter: | 450mm |
| Pump Shaft Power: | 991kw | Head: | 65m |
| Hydraulic System: | Rexroth | PLC: | Siemens |
| Width: | 10.02m | Transport Package: | Durable Package |
| Specification: | Total Length 38 M | Trademark: | Set Sail |
| Origin: | China | HS Code: | 895100000 |
| Supply Ability: | 500sets/Year | Package Size: | 3900.00cm * 880.00cm * 225.00cm |
| Package Gross Weight: | 180000.000kg | Type: | Cutter Suction Dredger |
| Power Type: | Electric | Cyclone Type: | Hydrocyclone |
| Samples: | US$ 500000/Set 1 Set(Min.Order) | | Customization: | Available | Customized Request |
| Shipping Cost : | About Shipping Cost And Estimated Delivery Time. | : | Initial Payment Full Payment |
| Currency: | US$ | Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
| Item / Information | Electric power water flow 3500m3 18 inch cutter suction dredger with underwater pump |
| Maily electric motor power | 1120kw |
| Auxiliary electric motor power | 355kw |
| Water flow | 3500m3 |
| Concentration | 30%-35% |
| Capacity | 1050m3-1225m3/h |
| Cutter head diameter | 1800mm |
| Cutter head power | 180 kw |
| Cutter teeth quantity | 50 piece |
Cutter head motor brand | XHS7C7-4300*5.5 |
| Pump size | 450NDQ |
| Pump shaft power | 991kw |
| Dreding depth | 18m |
| Discharge distance | 1500m |
| Hydraulic brand | Rexroth |
| PLC | Siemens |
| Frequency converter | GD350-1200G-6 |
| Frequency converter power | 1200kw |
| 1 | Cutter suction dredger is widely used in the river lake .sea .inland waterway and reservoir so on for dredging project |
| 2. | Cutter suction dredger is helpful for the port construction and match the wash sand equipment for project |
| 3. | Cutter suction dredger can match the mining machinery to get the gold and diamond etc. |
| 4. | Cutter suction dredger is suitable for all kinds of working situation , especially river with the high sand content and large project |
| 5. | Design of cutter suction dredger can reach the more dredger depth . we can make the design according to the dredging depth working site. |
Best parts will be used for the dredgers, like world famous Cumins engines, Shijiazhuang pumps, Hangzhou gearboxes, Simens PLC control system.
Hydraulic system is one of the most important parts of cutter suction dredgers. The cutter head, ladder winch, swing winches, spud or spud carriage are driven by hydraulic motors for higher efficiency and durability. Reputed brands are used for the other hydraulic parts like hydraulic pipes, hydraulic pumps, hydraulic valves.
