Product Details:
|
| Model NO.: | QHCSM-52 | Slot Type: | CTS |
|---|---|---|---|
| Customized: | Customized | Condition: | New |
| Warranty: | 2year | After-sales Service: | Lifelong |
| Main Engine Power: | Cummins 160kw-3000kw | Auxiliary Enigne Power: | Cummins 100kw-2000kw |
| Pump Size: | 250ND-800ND | Head: | 39-65m |
| Pump Discharge /Suction Pipe: | 200-900mm | Capacity: | 60-4000m3 |
| Water Flow: | 450-20000m3 | Discharge Distance: | 500-5000m |
| Total Weight: | 28-1000t | Cutter Head Power: | 50-450kw |
| Cutter Head Diameter: | 1000-3000mm | Gerbox Brand: | Fada |
| Hydraulic Brand: | Rexroth Parker | PLC: | Siemens |
| Fuel Consuption: | 34L-500L | Transport Package: | Container |
| Specification: | Max. Discharge Distance Over 5 Kilometer | Trademark: | Set Sail |
| Origin: | Qingzhou City Shandong Province China | HS Code: | 8905100000 |
| Supply Ability: | 5000set/Year | Package Size: | 3900.00cm * 880.00cm * 270.00cm |
| Package Gross Weight: | 230000.000kg | Lead Time: | 60 Days (1 - 1 Sets) To Be Negotiated ( > 1 Sets) |
| Type: | Cutter Suction Dredger | Power Type: | Diesel |
| Cyclone Type: | Hydrocyclone | Samples: | US$ 100000/Set 1 Set(Min.Order) | |
| Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
| : | Initial Payment Full Payment | Currency: | US$ |
| Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
| 1 | Cutter Head | 9 | Signal Light Support | 17 | Ventilator |
| 2 | Pulley for Ladder | 10 | Control Cabin Base | 18 | Spud |
| 3 | Pulley for Swing | 11 | Diesel Engine | 19 | Discharge Pipe |
| 4 | Anchor | 12 | 3 phase Electric Motor | 20 | Spud Holder |
| Ser. | Model | Pump | Dredging | Dimensions | Suction/Discharge | Engine(s) |
| Capacity | Depth | Pipe Dia. | Power | |||
| 1 | SETSAIL-CSD200 | 500m3/hr | 1-8m | 21*4.8*1.4m | 250/200mm | 224kw |
| 2 | SETSAIL-CSD250 | 800m3/hr | 1-10m | 25*5.2*1.6m | 300/250mm | 336kw |
| 3 | SETSAIL-CSD300 | 1200m3/hr | 1-12m | 27*5.4*1.6m | 350/300mm | 559kw |
| 4 | SETSAIL-CSD400 | 2200m3/hr | 1-14m | 33*6.4*1.8m | 400/400mm | 746kw |
| 5 | SETSAIL-CSD450 | 3000m3/hr | 1.5-15m | 38*7.3*2.0m | 500/450mm | 895kw |
| 6 | SETSAIL-CSD500 | 3500m3/hr | 1.5-16m | 40*7.8*2.0m | 600/500mm | 1231kw |
| 7 | SETSAIL-CSD550 | 4500m3/hr | 1.5-18m | 44*8.8*2.2m | 650/550mm | 1690kw |
| 8 | SETSAIL-CSD650 | 6000m3/hr | 1.5-20m | 48*9.0*2.4m | 650/650mm | 2270kw |
| 1 | ★ Modular design: The pontoons and main spare parts are connected by the bolts and nuts, which means the dredger can be dismantled in the factory and mounted in the construction sites. Of course, the delivery time will be reduced a lot by containers. |
| 2 | ★ World -class spare parts: We use the best parts like Cummins disel engine and Simmens PLC controlling system, Shijiazhuang pump.......Also, we build a efficient system to optimize the flow the production so as to guarantee the quality and function of the dredgers. |
| 3 | ★ Flexible in use: The dredgers can be adapted to different circumstance like river and lake. The material like sand, stones, mud, salt can be easily sucked and discharged to the destination place. |
| Qingzhou Setsail Dredging Machinery Equipment Co., Ltd. Is located in Qingzhou City Shandong Province China. total area near 90,000 m2. and more than 25 years manufacturing experience in water area environmental protective equipment. It is a professional supplier of integrated with R&D, consultation, manufacturing and after-sale service. Kehan now has obtained many certifications: CE, ISO9001:2015, ISO14001:14001, ISO45001. |
| The main productions like Cutter suction dredgers. Wheel bucket sucion dredger . chain bucket gold dredger . multi -fuction service working boat aquatic weed harvester and related equipment have been exported to near 100 areas and countries. |
| Setsail factoruy as the high-end brand and has been highly reputed by customers of its products' durable, high efficiency, low break down, short delivery time and professional field service. |
| With professional engineer teams. global trading teams. professional production process and CCS certified welders lead to Setsail's fast development today. Setsail is committed to creating a world famous brand in the field of water environment protection. |
| 1 |
|
| 2 |
|
| 3 |
|
| 4 |
|
| 5 |
|
| 6 |
|
| 7 |
|
