Product Details:
|
| Model NO.: | QHCSD-379 | Slot Type: | CTN |
|---|---|---|---|
| Customized: | Customized | Condition: | New |
| Warranty: | 2year | After-sales Service: | Lifelong |
| Engine Brand: | Cumins | Hydraulic Brand: | Rexroth |
| Generator Sets Brand: | Cumins With Stanford | Configuration: | Pressure Meter .Depth Meter Anchor Boom |
| Pump Brand: | Shijiazhuang | PLC Brand: | Siemens |
| Structure: | Box -Structure | Total Length: | 38m |
| Main Engien Power: | 1193kw | Auxiliary Engine Power: | 298 Kw |
| Generator Sets Power: | 40 Kw | Sand Pump: | 550 |
| Water Flow: | 4500m3 | Dredging Depth: | 15m |
| Discharge Distance: | 1500m | Transport Package: | In Bulk With Canvas |
| Specification: | 22 Inch River Sand Dredger | Trademark: | Set Sail |
| Origin: | Qingzhou City Shandong Province China | HS Code: | 8905100000 |
| Supply Ability: | 4000 Sets/ Year | Package Size: | 3900.00cm * 860.00cm * 225.00cm |
| Package Gross Weight: | 245000.000kg | Type: | Cutter Suction Dredger |
| Power Type: | Diesel | Cyclone Type: | Hydrocyclone |
| Samples: | US$ 4000/Piece 1 Piece(Min.Order) | | Customization: | Available | Customized Request |
| Shipping Cost : | About Shipping Cost And Estimated Delivery Time. | : | Initial Payment Full Payment |
| Currency: | US$ | Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
| Total length | 38m |
| Main engine brand /Power | Cumins /1193kw |
| Auxiliary engine brand /Power | Cumins /298kw |
| Harbour generator | Cumins 40kw |
| Dredging pump | Warma technology /550 (Shijiazhuang brand ) |
| Discharge pipe Inner diameter | 550mm |
| Maximum dredging depth | 20m |
| Maximum discharge distance | 2000m |
| Clear water flow | 4000-5000m3/h |
| Maximun capacity (Concentration 20%-30%) | 800-1500 m3/h |
| Cutter head diameter | 1700mm |
| Cutter head power | 260kw |
| Hydraulic system brand | Rexroth brand |
| PLC system | Siemens |
| Total fuel consumption | 229L/H |
| Modular design: | The pontoons and main spare parts are connected by the bolts and nuts. which means the dredger can be dismantled in the factory and mounted in the construction sites. Of course. the delivery time will be reduced a lot by containers. |
| World -class spare parts: | We use the best parts like Cumins disel engine and Simmens PLC controlling system.......Also. we build a efficient system to optimize the flow the production so as to guarantee the quality and function of the dredgers. |
| Flexible in use: | The dredgers can be adapted to different circumstance like river and lake. The material like sand. stones. mud. salt can be easily sucked and discharged to the destination place. |
| 1 | rivers. lakes. sea. reservoirs. port construction . land reclamation and dredging inland water way so on |
| 2 | rivers. lakes. reservoirs. pumping port dredging silt. |
| 3 | pumping sand beneficiation: Select iron sand pumping.pumping sand gold. rare earths. such as pumping sand election. |
| 4 | sewage treatment plant settling ponds cleanup. |
| 5 | municipal pipelines. storm water pumping station. hydroelectric sediment cleanup. |
| 6 | construction (sinking bridge construction. etc.) discharge of sediment. mud |
| 1 | Free dredger consulting. design and product drawings |
| 2 | Site visit and factory visit are provided .send the engineer to the working site then do the accurate design |
| 3 | Arrange 2-3 senior engineers and technicians to enter the work site within 36 hours |
| 4 | Free professional assembly. training and operation to ensure a smooth operation of the dredger |
| 5 | 2 year warranty. lifetime technical support |
| 6 | Sign after-sales service agreement with customer |
| 7 | Spare parts are supplied at a discounted price |
| 8 | Responsible sales team. design team. manufacturing team to provide customers with the best service 24/7. |
| Set Sail dredger factory covers an area of 1500 acres with more than 200 employees. |
| Factory has manufacture experience more than 20 years. |
| More than 50 certificated engineers and technicians. |
| We have certification and patent more than 50 item. It contains ISO CE etc. |
| Set Sail dredger is sold more than 80 countries . |
