Product Details:
|
| Model NO.: | QHWBD-46 | Customized: | Customized |
|---|---|---|---|
| Condition: | New | Warranty: | 2 Year |
| After-sales Service: | Lifelong | Power: | Diesel Engine Power |
| Control System: | Rexroth Hydraulic System | Application: | River . Lake . Sea . Reservoir . Pork |
| PLC: | Siemens | Diesel Engine Brand: | Cummims . Cat. Weichai |
| Total Length: | 17m-50m | Total Width: | 5.2m-12m |
| Total Height: | 1.5m-2.5m | Discharge Pipe Diameter: | 200mm-800mm |
| Water Flow: | 800m3-20000m3 | Dredging Depth: | 8m-20m |
| Discharge Distance: | 800m-5000m | Harbour Generator: | 20kw-200kw |
| Total Fuel Consumption: | 34L-518L/H | Total Power: | 224kw-2720kw |
| Transport Package: | Canvas And Container | Specification: | Capacity 160m3-2000m3 |
| Trademark: | Set Sail | Origin: | China |
| HS Code: | 8905100000 | Supply Ability: | 10000set/Year |
| Package Size: | 3800.00cm * 750.00cm * 200.00cm | Package Gross Weight: | 230000.000kg |
| Power Type: | Diesel | Cyclone Type: | Hydrocyclone |
| Slot Type: | CTS | Samples: | US$ 10000/Set 1 Set(Min.Order) | |
| Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
| : | Initial Payment Full Payment | Currency: | US$ |
| Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
| Wheel bucket dredger is big dredger with full hydrarulic control and assemble type . it is suitable for the dreging working of inland waterway . ditchs .river . lake .sea and reservoir .all dredger adopts hydraulic driving . centralized control . this dredger is conponent by third floating box . when using assembled into one body. driving roon is dismantled to suitable for the limited bridge . when the dredger is remote transfer and can not through the water eare , we can remove the dredger body to use the truck and train for transportation . wheel bucket dredger equipped anchor boom . spum trolley . booster station . concentrtation meter . water flow meter so on . cutter driving device adopts lubricating oil to ensure the long life . independent position metal floating ring seal . |
| Item \Size | QH-W200 | QH-W250 | QH-W300 | QH-W350 | QH-W400 | QH-W450 |
| Total length | 17m | 23m | 25m | 27m | 29m | 31m |
| Main diesel engine brand and power | Cummins/224kw | Cummins/298kw | Cummins/522kw | Cummins/731kw | Cummins/731kw | Cummins/895kw |
| Auxiliary diesel engien brand and power | ------------------ | ------------------- | -------------------- | Cummins/224kw | Cummins/224 | Cummins/224 |
| Harbour generator | Cummins/20kw | Cummins/20kw | Cummins/20kw | Cummins/30kw | Cummins/30kw | Cummins/30kw |
| Discharge pipe dia. | 200mm | 250mm | 300mm | 350mm | 400mm | 450mm |
| Max, dredging depth | 8m | 9m | 10m | 11m | 13m | 14m |
| Water flow | 800m3 | 1000m3 | 1500m3 | 2000m3 | 2500m3 | 3000m3 |
| Soild capacity | 160m3 | 200m3 | 300m3 | 400m3 | 500m3 | 600m3 |
| Discharge distance | 800m | 1000m | 1200m | 1500m | 1500m | 1500m |
| Hydraulic system | Siemens | Siemens | Siemens | Siemens | Siemens | Siemens |
| Total fuel consumption | 34L/H | 45L/H | 78L/H | 105L/H | 112L/H | 123L/H |
| Item \Size | QH-W500 | QH-W550 | QH-W600 | QH-W650 | QH-W700 | QH-W750 |
| Total length | 36m | 36m | 41m | 43m | 45m | 47m |
| Main diesel engine brand and power | Cummins/895kw | Cummins/1044kw | Cummins/1641kw | Cummins/1720kw | Cummins/2190kw | Cummins/2720 |
| Auxiliary diesel engien brand and power | Cummins/298kw | Cummins/298kw | Cummins/447kw | Cummins/456kw | Cummins/662kw | Cummins/738kw |
| Harbour generator | Cummins/40kw | Cummins/40kw | Cummins/50kw | Cummins/75kw | Cummins/75kw | Cummins/103kw |
| Discharge pipe dia. | 500mm | 550mm | 600mm | 650mm | 700mm | 800mm |
| Max, dredging depth | 15m | 16m | 16m | 17m | 18m | 20m |
| Water flow | 4000m3 | 4500m3 | 5500m3 | 6000m3 | 7000m3 | 7500m3 |
| Soild capacity | 800m3 | 900m3 | 1100m3 | 1200m3 | 1400m3 | 1500m3 |
| Discharge distance | 2000m | 2000m | 2000m | 2000m | 2200m | 2500m |
| Hydraulic system | Siemens | Siemens | Siemens | Siemens | Siemens | Siemens |
| Total fuel consumption | 179L/H | 201L/H | 313L/H | 326L/H | 428L/H | 518L/H |
| 1 | Best price low cost . we can provide the best price . let the customers spend the lowest cost get the biggest profit . |
| 2 | High efficiency . High quality configuration devices to achinece the high capacity the long time continue working time |
| 3 | Outstanding duration Reliable performance . all devices throughs the strict testing and from the known-well factory ,specially device imports abroad |
| 4 | Easy transportation . small size dredger is transproted by container . large size dreder is transported by the in bulk |
| 5 | Long service life and warrant . our warrant is normal 1year . specially prodcut is 2 year . |
| 6 | High quality . all spare parts from the know-well factory . almost apart part from the abroad |
| 7 | Easy maintenance . science design is conducive to the daily repair . manhole. test hole. and all lubricating system so on |
| 8 | Training service . free for trainling local workers until the they can expert the control whole the dredger |
| 1 | Inquiry and consulting support. Our service team all online to guide for every problem |
| 2 | Sample sand dredger testing support. We have testing support for all dredger |
| 3 | View our Factory. Welcome to inspect factory |
| 4 | Training how to install the sand dredger boat, training how to use the sand dredger .training how to repair dredger |
| 5 | Engineers available to service sand dredger boat overseas. When the complex failure we will send the engineer to oversea |
| 6 | After sales team in Nigeria, India, Bangladesh, Colombia etc for 24h sand dredger boat after-sale service |
| 7 | we can offer the all guide service :assemble .repair and free for training the local workers |
| Set Sail dredger factory covers an area of 1500 acres with more than 200 employees. |
| Factory has manufacture experience more than 20 years. |
| More than 50 certificated engineers and technicians. |
| We have certification and patent more than 50 item. It contains ISO CE etc. |
| Set Sail dredger is sold more than 80 countries . |
| We have full range of dredging equipment for CSD dredger . jet suction dredger,.Wheel bucket Dredger. Bucket chain dredger. gold mining equipment. work boat. Tailing suction dredger and sand transportation boat etc. |
