Product Details:
|
| Model NO.: | LM-50 | Material: | Carbon Steel |
|---|---|---|---|
| Material Feature: | Corrosion Resistant | Energy Saving: | Energy Saving |
| Warranty: | 1 Year | Color: | Multi Color |
| Customized: | Customized | Condition: | New |
| After-sales Service: | Lifelong | Total Length: | 4-10 Meter |
| Capacity: | 50-500 Ton | Mainly Fream Heitht: | 4-8 Meter |
| Feeding Machine Power: | 10-100kw | Bucket Quantity: | 20-60 Set |
| Bucket Capacity: | 0.07m3 | Lifting Power: | 2.0-10kw |
| Drum Screen Power: | 10kw-50kw | Water Flow: | 200m3/H |
| Head: | 8-15 Meter | Built Chute Working Length: | 2 Meter |
| Centrifuge Power: | 7.5-50kw | Centrifuge Quantity: | 2 Sets |
| Diesel Engine Brand: | Cummins Or Weichai | Total Fuel Consumption: | 18-50L |
| Transport Package: | Canvas Or Bulk | Specification: | Capacity 50m3-500m3 |
| Trademark: | Set Sail | Origin: | China |
| HS Code: | 8905100000 | Supply Ability: | 5000 Set /Year |
| Type: | Gravity Separator | Voltage: | 380V |
| Weight: | >10T | Samples: | US$ 3000/Set 1 Set(Min.Order) | |
| Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
| : | Initial Payment Full Payment | Currency: | US$ |
| Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
| 1 | Land gold |
| 2 | Land diamond |
| 3 | Land gold and diamond |
| Specifications of Professional Diamond Mining Equipment Machine on sale | |||
| Model | Set Sail 50 | Set Sail 100 | Set Sail 200 |
| Parameters | |||
| Size /mm | 7000*2000*3000 | 8300*2400*4700 | 9800*3000*5175 |
| Capacity | 50-80 tph | 100-150 tph | 200-300 tph |
| Power | 50 kw | 120 kw | 150 kw |
| Feeder Hopper /mm | 2000*2200 | 3000*2200 | 3800*3000 |
| Clay Scrubber /mm | φ1000*2000 | φ1200*3000 | φ1500*3000 |
| Trommel Screen /mm | φ1200*3000 | φ1500*3500 | φ1800*4000 |
| Sluice Box | 2 sets | 3 sets | 4 sets |
| Water Supply /m³ | 120 m³ | 240 m³ | 370 m³ |
| Wheels | 6 wheels | 10 wheels | 10 wheels |
| Recovery Rate | 98% | 98% | 98% |
6.Feature: | 1 | simple structure . portable machiner conbine togehter |
| 2 | This machiner can elect gold and diamond in the same time |
| 3 | High recovery gold and diamond ratio. |
| 4 | Low failure . High capacity . |
| Set sail factory is found in 1992 . it is one of the leader of china dredging machinery equipment industrial. We have manufacture experience more than 20 years so far. Our mainly product : all kinds power of cutter suction dredger (electric hydraulic ) jet suction dredger trailing suction dredger wheel suction dredger chain bucket dredger chain bucket mining dredger land mining machinery multi-function service working boat sand transportation boat sand wishing machinery etc. We can according to customers requirement to make the design and customize the product . |
