Product Details:
|
| Model NO.: | Amphibious-5 | Slot Type: | CTS |
|---|---|---|---|
| Customized: | Customized | Condition: | New |
| Warranty: | 1 Year | After-sales Service: | Long |
| Power: | Diesel Engine | Hydraulic Brand: | Rexroth |
| Application: | River .Reservoir . Lake | Name: | Amphibious Dredger |
| Sand Pump Brand: | Kingda | Diesel Engine Brand: | Cummins |
| PLC Brand: | Siemens | Optional Digging Tool: | Bucket . Rake. Cutter Head |
| Transport Package: | Mute | Specification: | Capacity 120m3-700m3/h |
| Trademark: | Set Sail | Origin: | Qingzhou City Shandong Province China |
| Supply Ability: | 500 PCS /Year | Package Size: | 1800.00cm * 400.00cm * 400.00cm |
| Package Gross Weight: | 40000.000kg | Lead Time: | 40 Days (1 - 1 Pieces) To Be Negotiated ( > 1 Pieces) |
| Type: | Amphibious Dredger | Power Type: | Diesel |
| Cyclone Type: | Hydrocyclone | Samples: | US$ 20000/Piece 1 Piece(Min.Order) | |
| Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
| : | Initial Payment Full Payment | Currency: | US$ |
| Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
| 1 | Disposal easily, no need for crane, can move on a road and get in and out of the water without too much cost |
| 2 | Work stable, with spuds and support legs to keep balance |
| 3 | One person operation. Workers with excavator operation skills can operate easily after a little training |
| 4 | Lights on dredger are available to make sure constant work for maximum efficiency |
| 5 | Self-propulsion with propellers |
| 6 | High efficiency, with submersible mud pump and cutter compound equipment ensuring high slurry density (around 25%) |
7 | Can be used in closed channel, shallow areas, ind7ustrial pond, reservoir etc. where other dredgers can not work |
| 8 | Strong marine steel construction |
| 9 | Hydraulic track drive through hydraulic motors. |
| 10 | Low ground pressure and good clearance on terrain, marches and swamps during on-land drives |
| No. | Name | Specification |
| 1 | Size(L*W*H) | 11*3.3*3.1m |
| 2 | Weight | 25t |
|
3 | Engine | Cumins Made In China |
| 4 | Hydraulic System | Rexroth brand made in Germany |
| 5 | Excavator |
|
|
| Swinging angle | 180º |
|
| Lifting capacity at max. reach | 22kN |
| 6 | Dredge Pump |
|
| Outlet diameter | 250mm | |
| Max. dredging depth | 6.5m | |
| Max. discharging distance | 1500m | |
| Water flow | 400m3/h | |
| 7 | Optional Equipment | Suction pump, discharge pipe, nozzle, rake, clam shell, vertical pile bucket, steel sheet pile head, maintenance crane, crawler pontoon |
| Model | QHAM 260 | Transport Dimensions | 11m*3.3m*3.05m |
| Pontoon Material | CCSB Steel Plate | Engine Power | 269KW |
| Max Working Depth | 4m | Arm Lenth | 7m |
| Dredge pump | Pump flow - 500m³/h | Type | submersible pump |
| Dredging depth | 6.0m | Discharge distance | 1500m |
| Front stabilizer max depth | 5.0m | Rear stabilizer max depth | 6.0m |
